A VoIP Gateway (also called GOIP Gateway) is a device that connects mobile networks (2G/4G) to IP networks. It lets you make voice calls and send SMS through both mobile networks and the internet. YX VoIP Gateway works with 2G GSM and 4G LTE networks, making it flexible for different regions and needs.
YX VoIP Gateway is designed for bulk communication. It supports:
- Sending bulk SMS to customers, clients, or users
- Making mass voice calls for notifications, reminders, or marketing
- Managing multiple calls and messages at the same time
- Integrating with IP-based systems (like SIP) for unified communication
- Saves time: Handle hundreds of calls or SMS at once, no need for manual operation
- Cuts costs: Lower communication fees compared to traditional phone lines
- Boosts efficiency: Ideal for customer service centers, marketing teams, or businesses needing frequent mass outreach
- Global reach: Works in most countries with 2G or 4G networks
YX VoIP Gateway uses reliable modules to ensure network compatibility worldwide:
- M26/M35: Support 2G GSM full frequency (850/900/1800/1900MHz). Works in countries with active 2G GSM networks.
- Note: Australia, South Korea, Japan, the US, and Canada have shut down 2G, so 2G gateways won’t work there.
- EC25-EUX: For Asia, Europe, Africa, the Middle East, Southeast Asia (Vietnam, Myanmar, etc.).
- Supports LTE FDD (B1/B3/B5/B7/B8/B20/B28), LTE TDD (B38/B40/B41), WCDMA (B1/B5/B8), GSM (B3/B8).
- EC25-AFX: For the US and Canada.
- Supports LTE FDD (B2/B4/B5/B12/B13/B14/B66/B71), WCDMA (B2/B4/B5).
- EC25-AUX: For Australia, New Zealand, Latin America (Mexico, Brazil, etc.).
- Supports LTE FDD (B1/B2/B3/B4/B5/B7/B8/B28/B66), LTE TDD (B40), WCDMA (B1/B2/B4/B5/B8), GSM (B2/B3/B5/B8).
- EC25-J: For Japan.
- Supports LTE FDD (B1/B3/B8/B18/B19/B26), LTE TDD (B41), WCDMA (B1/B6/B8/B19).
- EC20: For China and India.
- Supports LTE FDD (B1/B3/B5/B8), LTE TDD (B34/B38/B39/B40/B41), WCDMA, TD-SCDMA, EVDO CDMA, GSM.
YX VoIP Gateway offers various port and SIM slot options to match your needs. Each port supports simultaneous voice calls or SMS.
- 4 Port: 4 port 4 sim (4 ports, 4 SIM cards) Handles 4 simultaneous calls/SMS.
- 8 Port: 8 port 8 sim; 8 port 32 sim. Handles 8/32 simultaneous calls/SMS.
- 16 Port: 16 port 16 sim; 16 port 64 sim; 16 port 128 sim; 16 port 256 sim; 16 port 512 sim. Handles 16/64/128/256/512 simultaneous calls/SMS.
- 32 Port: 32 port 32 sim; 32 port 128 sim; 32 port 256 sim; 32 port 512 sim. Handles 32/128/256/512 simultaneous calls/SMS.
- Voice & SMS: Supports SIP voice (RFC3261) and SMS (SMPP3.4, HTTP, API).
- Network Protocols: DHCP, PPPoE, Static IP, VPN for stable connections.
- Additional Functions: STK, AT Command, TCP/IP, Data, MMS, Email, GPRS, GPS, USSD.
- Telephony Features: Call forward, speed dial, white/black list, CDR (call detail records).
- Voice Quality: Codecs like G711, G729; echo cancellation, noise suppression.
- Insert SIM cards into the gateway’s SIM slots.
- Connect the gateway to power (100-240VAC) and your network (Ethernet).
- Configure settings via the web interface (use SIP, STUN, or AT commands as needed).
- Use software (compatible with your system) to manage calls/SMS.
- Monitor status via LED indicators (power, card online/running).
YX Series GP User Manual.pdf (Voip Gateway Product Manual)
- Global Compatibility: Supports 2G/4G networks in most countries with region-specific modules.
- Scalable Options: 4-32 ports and up to 512 simultaneous calls/SMS to fit small to large businesses.
- Reliable Performance: 12-month warranty and technical support.
- Cost-Effective: Lower communication costs than traditional lines; USDT payment gets 1% discount.
